SCR Characteristics Apparatus

SCR Characteristics Apparatus
SCR Characteristics Apparatus
Product Code : AS-106
Brand Name : Astar
Product Specifications
  • Product Type
  • BASIC ELECTRONICS LAB
  • Material
  • BACKALIGHT PANEL AND ABS CABINET
  • Size
  • 12" X 8" APPROX
Product Description

We are an eminent firm, manufacturing and supplying an extensive assortment of SCR Characteristics Apparatus, which is provided with working manual & patch cords and used to study Forward & Reverse V-I Characteristics of Zener diode. This apparatus is designed with premium quality material and strong circuit connections, thus it is sturdy and has degradation resistance. This apparatus is easy to use, compact and easy to operate. We are providing this SCR Characteristics Apparatus at affordable rates.

Features:

  • Optimum quality
  • Precisely designed
  • Long life





OTHER DETAILS:

1. The two incessantly changeable DC regulated power supplies of 0-30V and 0-1V.

Specifications of Regulated Power Supply :

  • Input Voltage : 230 V +10% AC, 50 Hz
  • Load Standard (regulation) : + 0.2%
  • Line Regulation : + 0.05%
  • Rippling : Less than 3 mV R.M.S.(Root-mean-square )
  • Protections : Given against Over Load and Short Circuits

2. Three meters for the measurement of Voltage & Current are affixed on the head-on panel & connections carried out on 4mm Sockets.

3. SCR arranged inside the cabinet and couplings are presented on sockets.












Trade Information
  • Main Domestic Market
  • All India
